Accessing the DivePort Web API

Data in the DivePort Web API is accessible via two methods: Connecting through code, or logging into the API in a web browser.

NOTE: A user access token is required to access the Web API. For more information, see Workbench Help

Accessing the Web API in Code

You can access the DivePort Web API with any code process that supports web APIs. To use the API you must authenticate with an access token (password authentication is not supported). There are two ways to authenticate with the API:

Passing the access token in the URL query (token=...).
Through the HTTP header (Authorization: Bearer ...).

For single synchronous requests, using an access token with these authentication methods are convenient because the client does not need to keep track of any session state. However it is slower for multiple requests, and you cannot run asynchronous requests using these methods.

The alternative method to authenticate is to start a session by logging in using the /api/login URL ending. That request returns a session token, which can be used instead of your access token for future requests. This is much faster for subsequent requests, and it allows the use of asynchronous requests.

The session will time out if it is idle for 2 minutes. To keep the session active, such as in situations where user input is required, you can periodically send a simple request such as /api/info to keep the session active.

Examples

Python - Synchronous Request

This example returns summary data from a cBase as plain text, using a single synchronous request.

Copy

from urllib.parse import quote
from urllib.request import urlopen

access_token = "ditok-AAAAAAAAAAAAAAAAAAAA"

response = urlopen("https://my-site.example.com/diveport/api/query"
    + "/" + quote("My Project") + quote("/cbases/My Data.cbase")
    + "?token=" + access_token
    + "&dimension=" + quote("Customer")
    + "&column=" + quote("Units")
    + "&format=tsv")
print(response.read())

Python - Asynchronous Request

This example uses asynchronous requests to get the first 100 results of a query

Copy

from urllib.parse import quote
from urllib.request import urlopen
import json
from time import sleep

access_token = "ditok-AAAAAAAAAAAAAAAAAAAA"

# Log in to create a session and get the session token
response = urlopen("https://my-site.example.com/diveport/api/login"
    + "?token=" + access_token)
response_json = json.loads(response.read())
session_token = response_json["sessionToken"]

# Start an asynchronous query and get the job ID
response = urlopen("https://my-site.example.com/diveport/api/async/query"
    + "/" + quote("My Project") + quote("/cbases/My Data.cbase")
    + "?token=" + session_token
    + "&dimension=" + quote("Customer")
    + "&column=" + quote("Units")
    + "&format=tsv")
response_json = json.loads(response.read())
job_id = response_json["jobId"]

# Wait for the job to finish
while True:
    response = urlopen("https://my-site.example.com/diveport/api/async/job"
        + "/" + job_id)
    response_json = json.loads(response.read())
    if response_json["status"] == "complete":
        break
    sleep(1)

# Get the first 100 rows as JSON
response = urlopen("https://my-site.example.com/diveport/api/async/job"
    + "/" + job_id + "/data"
    + "?limit=100")
response_json = json.loads(response.read())
print(json.dumps(response_json["rows"]))

cURL - Synchronous Request

This example returns summary data from a cBase as plain text, using a single synchronous request.

Copy

curl -s "https://my-site.example.com/diveport/api/query/My%20Project/cbases/My%20Data.cbase?token=ditok-AAAAAAAAAAAAAAAAAAAA&dimension=Customer&column=Units&format=tsv"
